DG-Stomp
3
SPECIFICATIONS
Digital Section
• Full Digital Signal Processing
• 8 Channel Preamp
• Digital Effects
• Compressor
• Chorus, Flanger, Phaser, Rotary Speaker, Tremolo
• Digital Delay, Tape Echo
• Spring Reverb, Hall Reverb, Plate Reverb
• Tap Tempo Function (Delay Time)
• Speaker Simulator (16 Types)
• External Controller Function (EXP Pedal/MIDI):8 Controllers/
Parameters
• Wah Function
• Tuner Function (Chromatic, Auto)
MIDI Functions
Receive: Program Change (Program Change Table can be
created), Control Change, Bulk In
Transmit: Program Change, Control Change, Bulk Out, Merge
Out
Controller Switch
Top Panel
Push Switch x17
UP, DOWN, MANUAL, UTILITY, STORE, COMP, CHORUS,
FLANGER, PHASER, ROTARY, TREMOLO, DELAY, TAPE
ECHO, SPRING, HALL, PLATE, SP. SIM
Knob x15
AMP SELECT, GAIN, MASTER, TREBLE, MIDDLE, BASS,
PRESENCE, COMP, SPEED, DEPTH, TIME, FEEDBACK,
LEVEL, REVERB, OUTPUT
Footswitch x4
1, 2, 3, BANK
Rear panel
STAND-BY ON/OFF, INPUT LOW/HIGH
Display
7 Segment LED (3 digit) x1
Push Switch LED x17
Foot Switch LED x4
Connections/Jacks
INPUT: Standard Monaural Phone Jack
OUTPUT L/MONO, R: Standard Monaural Phone Jack
PHONES: Standard Stereo Phone Jack
EXP. PEDAL: Standard Stereo Phone Jack
DIGITAL OUT: COAXIAL
MIDI IN, MIDI OUT: 5 pin DIN
A/D Converter
20 bit + 3 bit Floating
D/A Converter
20 bit
Sampling Frequency
48 kHz
Memory Allocations
Preset: 90
User: 90
Input Level/Impedance
(When using preamp bypass)
INPUT HIGH: -25dBm/1Mohm
INPUT LOW: -15dBm/1Mohm
Output Level/Impedance
OUTPUT L/MONO, R: 0dBm/1kohm
PHONES: 0dBm/47ohms (47ohms load)
Power
Exclusive Power Adaptor (AC-10)
AC Output: AC12V, 1000mA
Power Consumption
15W
Dimensions (WxHxD)
280x70x184mm (11.0”x2.8”x7.2”)
Weight
2.2kg (4lbs 14oz)
Accessories
Power Adaptor (AC-10)
Owner’s Manual (this booklet)
