Yamaha DG-Stomp - Page 35

DG-Stomp
3
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK: Japan only
*
*
*
*
*
*
*
*
*
*
*
*
OVERALL ASSEMBLY DG-STOMP
Overall Assembly (V573350)
10 Top Cover Assembly (V573420)
10a Top Cover
10b Meter Cover
10c Bind Head Tapping Screw-B 3.0X8 MFZN2BL 701
10d Circuit Board Assembly (V600780)
10d-1 Circuit Board DG-STOMP
10d-2 Lithium Battery CR2450 03
10e Hexagonal Nut 9.0 12X2 MFNI33 501
10f Flat Washer 9X14 0.5 FNM3 501
10g Toothed Lock Washer-A 9.0 MFZN2Y 501
10h Circuit Board Assembly (V600800)
10i Shield Film (V585150)
10j Bind Head Tapping Screw-P 3.0X12 MFZN2BL 301
20 Bottom Case
30 Bind Head Tapping Screw-B 3.0X8 MFZN2BL 601
40 Knob (CH) DG60-112 702
50 Spacer
60 Knob (FX) 8
70 Button(S) GRAY 01
80 Button(L) NO.947 CD-GRAY 01
100 Leg SR200 401
Circuit Board Assembly PN (V600800)
Circuit Board (AAX19500+AAX19510) (V587990)
P10-1 Circuit Board
P10-2 Circuit Board (Foot SW Sheet)
P20 Button 17
P30 Wire Assembly C&C #28 12P L100 (V611450)
P40 Wire Assembly C&C #28 11P L100 (V611460)
P50 Wire Assembly C&C #28 9P L100 (V611470)
P60 Wire Assembly C&C #28 6P L250 (V611480)
P90 Wire Assembly C&C #28 14P L 50 (V610850)
Accessories
AC Adapter AC-10 J J
AC Adapter AC-10 U,C U, C
AC Adapter AC-10 H H
--
--
V5734300
V5734500
EP600190
--
V5880000
VS246400
LX200060
VL802300
ET800150
--
--
VC161100
V5734400
EP600190
V3694100
V5851800
V5852300
VZ429100
VZ968600
VU859300
--
--
AAX19500
AAX19510
V5852100
--
--
--
--
--
V5882800
V5883000
V5883100
