Yamaha DG-Stomp - Electrical Parts - Quartz Units, Diodes, ICs, Connectors

DG-Stomp
8
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK: Japan only
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
X1 Quartz Crystal Unit 30.00M HZ DOC-49S2 06
X2 Quartz Crystal Unit AT-49/12.0000MHZ 03
X101 Quartz Crystal Unit 24.576M AF3817CQA 03
ZD101 Zener Diode UDZ 2.0BTE-17 2.0V
ZD102 Zener Diode UDZ 2.0BTE-17 2.0V
ZD103 Zener Diode UDZ 15B TE-17 15V
ZD104 Zener Diode UDZ 15B TE-17 15V
Circuit Board PN (V587990)
Spacer 8
LED Holder LED3-1A 4
Wire Assembly C& #24 2P L60 (V654510) 4
Push Switch ADS-003-A10 4
C301 Electrolytic Cap.(chip) 0.1000 25V Z
-315 Electrolytic Cap.(chip) 0.1000 25V Z
CN301 Connector Base Post M2426XXR 6P SE 01
CN302 Connector Base Post M2426XXR 9P SE 01
CN303 Connector Base Post M2426XXR 11P SE
CN304 Connector Base Post M2426XXR 12P SE 01
CN305 Connector Base Post M2426XXR 14P SE 01
CN306 Connector Base Post M2426XX 14P TE
CN307 Connector Base Post M2426XX 2P TE 01
CN308 Connector Base Post M2426XX 2P TE 01
-310 Connector Base Post M2426XX 2P TE 01
D301 Diode 1SS355 TE-17 01
-321 Diode 1SS355 TE-17 01
IC301 IC 74HC374DT D-FF
-307 IC 74HC374DT D-FF
IC308 IC 74HC4052DT MULTIPLEXER
IC309 IC 74HC4052DT MULTIPLEXER
K301 Style Pin IMSA-6024 01
LD301 LED Display LTC-5836E
LD302 LED Red LT311G-41-C13 01
-304 LED Red LT311G-41-C13 01
LD306 LED Red LT311G-41-C13 01
L301 Chip Inductance BLM21B751S 2125 03
-312 Chip Inductance BLM21B751S 2125 03
R301 Carbon Resistor (chip) 10K 0.1 J
-304 Carbon Resistor (chip) 10K 0.1 J
R305 Carbon Resistor (chip) 560 0.1 J
-321 Carbon Resistor (chip) 560 0.1 J
R322 Carbon Resistor (chip) 820 0.1 J
-345 Carbon Resistor (chip) 820 0.1 J
R346 Carbon Resistor (chip) 10K 0.1 J
-360 Carbon Resistor (chip) 10K 0.1 J
R361 Carbon Resistor (chip) 1.0K 0.1 J
-367 Carbon Resistor (chip) 1.0K 0.1 J
R368 Carbon Resistor (chip) 10K 0.1 J
R369 Carbon Resistor (chip) 10K 0.1 J
R370 Carbon Resistor (chip) 560 0.1 J
-374 Carbon Resistor (chip) 560 0.1 J
R376 Carbon Resistor (chip) 0 0.1 J
SW301 Push Switch SKHQFN GREEN 02
-317 Push Switch SKHQFN GREEN 02
SW318 Rotary Switch SRBV18 1C-8S 07
VR301 Rotary Variable Resistor RK09L1140 10KB
-313 Rotary Variable Resistor RK09L1140 10KB
VR314 Rotary Variable Resistor RK09L12D0 20KA X2
VU682100
VE463500
VN277000
VU170900
VU170900
VU173000
VU173000
--
V6220800
V6624600
--
V6124500
UX145100
UX145100
VV068000
VV068300
VV068500
VV068600
VV068800
VV067400
VV066200
VV066200
VV066200
VT332900
VT332900
XZ102A00
XZ102A00
XZ101A00
XZ101A00
VB966900
V5801000
VV620800
VV620800
VV620800
VS740100
VS740100
RG007100
RG007100
RG005560
RG005560
RG005820
RG005820
RG007100
RG007100
RG006100
RG006100
RG007100
RG007100
RG005560
RG005560
RG000000
VK701100
VK701100
V3633800
V5264800
V5264800
V5265100
