Yamaha DG-Stomp - Amplifier Section Controls; Effect Section Controls

DG-Stomp
6
13
14
15
16
17
18
19
20
21
22
23
Amp Section
7
8
9
10
11
12
Amp Select Switch (LEAD1-CLEAN2)
Gain Control (GAIN)
Master Volume (MASTER)
Tone Controls
Output Level Control (OUTPUT)
Speaker Simulator Button (SP. SIM)
Compressor Button (COMP)
Compressor Knob (COMP)
Modulation Group Effect Buttons
(CHORUS/FLANGER/PHASER/ROTARY/TREMOLO)
Speed Knob (SPEED)
Depth Knob (DEPTH)
Delay Group Effect Buttons(DELAY/TAPE ECHO)
Time Knob (TIME)
Feedback Knob (FEEDBACK)
Level Knob (LEVEL)
Reverb Group Effect Buttons(SPRING/HALL/PLATE)
Reverb Knob (REVERB)
!5
!4 !6 !7 !9 @0 @1 @3
!8 @2!3
Effect Section
u i o !0
!1
!2
