DSP-A5
PRY
PRY
SI2
SI2
MG
MG
W856 BR
W854 BE
W855 OR
W856B
W802B
W854B
W852B
W855B
W851B
W853B
W801B
W852 WH
W853 RE
W851 YE
W801 GY
W802 BR
W853A
W852AW851A
W855A
W856A
W802A
W801A
W854A
TO:POWER TRANSFORMER
TO:MAIN(3)
1
2
3
4
5
6
7
8
VOLTAGE SELECTOR
SWITCHED
100W MAX. TOTAL
AC OUTLETS
J, B and G models
P. C. B. POWER (2)
E-32/J-30
BACDEFH
G
1
2
3
4
5
6
PRINTED CIRCUIT BOARD (Foil side)
E-33/J-31
R and T models
P. C. B. POWER (2)
PRY
PRY
SI2
SI2
MG
MG
W802A W802B
W802 BR
W801 GY
W801A
W801B
TO:MAIN(3)
TO:
POWER TRANSFORMER
SWITCHED
100W MAX. TOTAL (J model)
AC OUTLETS
SWITCHED
100W MAX. (B model)
100W MAX. TOTAL (G model)
AC OUTLETS
B,G modelsJ model
J,B only
G only
R and T models only
P. C. B. POWER (6)
R and T models only
P. C. B. POWER (4)
J, B and G models only
P. C. B. POWER (7)
Ref. No. Location
D801 D2
D804 D3
D805 D3
D806 D2
D807 D2
Q801 D2
Semiconductor Location
J,B,G models
Ref. No. Location
D801 D4
D803 D5
D804 D5
D805 D5
D806 D5
D807 D5
Q801 D5
Q802 D5
Semiconductor Location
R,T models
240V 1-2 / 5-6
220V 2-3 / 6-7
110V 3-4 / 7-8
120V 4-5 / 8-1
