● 5 Speaker Configuration
Main: 65 W + 65 W (8Ω) RMS Output
Power, 0.04% THD, 20 Hz – 20 kHz
Center: 65 W (8Ω) RMS Output
Power, 0.04% THD, 20 Hz – 20 kHz
Rear: 65 W + 65 W (8Ω) RMS Output
Power, 0.04% THD, 20 Hz – 20 kHz
● Digital Sound Field Processor
● Dolby Digital Decoder
● Dolby Pro Logic Surround Decoder
● CINEMA DSP: Theater-like Sound
Experience by the Combination of Dolby
Surround and YAMAHA DSP Technology
● 6-Channel External Decoder Input for DTS
and other future formats
SUPPLIED ACCESSORIES........................................... 2
FEATURES .................................................................... 3
CAUTION ....................................................................... 4
● Introduction
FEATURES ON SOUND EFFECT ................................. 5
CONTROLS AND THEIR FUNCTIONS ......................... 7
● Preparation
SPEAKER SETUP ....................................................... 10
CONNECTIONS........................................................... 12
ADJUSTMENTS
BEFORE USING THIS UNIT .................................. 19
● Basic Oparation
BASIC OPERATIONS .................................................. 24
SETTING THE SLEEP TIMER..................................... 28
● Information about DSP
USING DIGITAL SOUND FIELD
PROCESSOR (DSP) .............................................. 29
● Advanced Information
ADJUSTMENTS
IN THE “SET MENU” MODE................................... 35
● Remote Control Transmitter
REMOTE CONTROL TRANSMITTER ......................... 37
SETUP CODES ........................................................... 42
NOTES ABOUT THE REMOTE CONTROL
TRANSMITTER ...................................................... 43
TROUBLESHOOTING ................................................. 44
SPECIFICATIONS ....................................................... 46
LIST OF MANUFACTURER’S CODE ........................ 311
FEATURES
CONTENTS
● Automatic Input Balance Control for
Dolby Pro Logic Surround
● Test Tone Generator for Easier Speaker
Balance Adjustment
● Speaker Output Mode Changing
Capability
● Video Signal Input/Output Capability
(Including S Video Connections)
● SLEEP Timer
● Universal Remote Control
Transmitter with Preset Manufacturer
Codes
