CONNECTIONS
Never plug in this unit and other components until all connections are completed.
CONNECTIONS WITH OTHER COMPONENTS
When making connections between this unit and other components, be sure all connections are made correctly, that is to say L
(left) to L, R (right) to R, “+” to “+” and “–” to “–”. Also, refer to the owner’s manual for each component to be connected to this unit.
* If you have YAMAHA components numbered as !, @, #, $, etc. on the rear panel, connections can be made easily by making
sure to connect the output (or input) terminals of each component to the same-numbered terminals of this unit.
, : See the next page.
Turntable Monitor TV
DVD player, LD player, etc.
CD player Tape deck,
MD recorder, etc.
TV/DBS tuner VCR
(Video cassette recorder)
To AC outlet
(Eupore model)
Tuner
