9
English
1 Multi-information display
Displays various information, for example name of selected
DSP program and name of selected input source.
2 TAPE/MD MON indicator
Lights up when the tape deck (or MD recorder etc.) is selected as
the input source by pressing TAPE/MD MON / EXT. DECODER
on the front panel or TAPE/MD on the remote control transmitter.
DISPLAY PANEL
3 , and indicators
“
” lights up when the built-in Dolby Digital decoder is
on and the signals of selected source encoded with the Dolby
Digital is not in 2-channel. “ ” lights up when the built-in
digital sound field processor is on, and “
” lights up
when the built-in Dolby Pro Logic Surround decoder is on.
Depending on the selected DSP program, both “ ” and
“ ”, or both “ ” and “ ” will light up.
4 SLEEP indicator
Lights up while the built-in SLEEP timer is functioning.
DSP-A595-1 3/25/99, 3:53 PM9
