Yamaha DSP-AX2 Service Manual

DSP-AX2
99 100
■ MECHANICAL PARTS
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
* 1‑1 V6076700 FRONTPANEL TI
* 1‑1 V6066000 FRONTPANEL BL
* 1‑1 V6066100 FRONTPANEL GD
* 1‑3 V6065300 SUPPORT/ESC
* 1‑4 V6066900 ESCUTCHEON/SIDE R BL
* 1‑4 V6077300 ESCUTCHOENSIDE R TI
* 1‑4 V6067000 ESCUTCHEON/SIDE R GD
* 1‑5 V6077400 ESCUTCHOENSIDE L TI
* 1‑5 V6067200 ESCUTCHEON/SIDE L GD
* 1‑5 V6067100 ESCUTCHEON/SIDE L BL
* 1‑6 V6070200 ESCUTCHEON/POWER
* 1‑7 V6070400 ESCUTCHEON,SEL
* 1‑8 V6004800 EMBLEM BL,TI
* 1‑8 V6004900 EMBLEM GD
* 1‑9 V6070000 WINDOWPANEL,LID
* 1‑10 V6070800 SPACER/SIDE R
* 1‑11 V6070900 SPACER/SIDE L
* 1‑12 V6066500 PANEL/SIDE R BL
* 1‑12 V6077100 PANEL/SIDE R TI
* 1‑12 V6066600 PANEL/SIDE R GD
* 1‑13 V6077200 PANEL/SIDE L TI
* 1‑13 V6066700 PANEL/SIDE L BL
* 1‑13 V6066800 PANEL/SIDE L GD
* 1‑14 V4656400 SPECIALSCREW 4‑7MFNI3B TI
* 1‑14 V4656300 SPECIALSCREW 4‑7MFZN2‑BL BL
* 1‑14 V4656500 SPECIALSCREW 4‑7MFNI33 GD
* 1‑15 V6893800 FLATHEADB‑TITESCREW 2.6x8MFZN2‑BL
* 1‑16 EG330360 BINDHEADSCREW 3x6ZMC2‑BL
2‑1‑3 VZ619800 SUPPORT HINGE
* 2‑1‑4 VZ830500 SUPPORT MG
2‑1‑5 VZ621800 SHAFT AA
* 2‑1‑6 VZ621900 MAGNET
* 2‑1‑11 V6066400 PANEL,LID GD
* 2‑1‑11 V6076900 PANEL,LID TI
* 2‑1‑11 V6066300 PANEL,LID BL
* 2‑1‑13 V6067700 PLATE,SP GD
* 2‑1‑13 V6077600 PLATE,SP TI
* 2‑1‑13 V6067600 PLATE,SP BL
* 2‑1‑15 V6068500 SUBPANELCASE GD
* 2‑1‑15 V6068400 SUBPANELCASE BL
* 2‑1‑15 V6095500 SUBPANELCASE TI
2‑1‑16 VT062900 CUSHION,LID BL
2‑1‑16 VU182300 CUSHION,LID TI
2‑1‑16 V2048500 CUSHION,LID GD
* 2‑1‑17 V6996800 SPACER/MG
2‑1‑18 VH625500 DAMPER
2‑1‑21 V0050300 STOPPER HINGE GD
2‑1‑21 VJ888100 STOPPER HINGE BL,TI
* 2‑1‑22 VZ830400 HINGE/MG TI
2‑1‑22 V0047400 HINGE/MG GD
2‑1‑22 VZ629400 HINGE/MG BL
2‑1‑23 VZ830300 DAMPER,GEAR 15G
2‑1‑24 VQ541700 PWHEADB‑TITESCREW 3x8‑8MFC2
* 2‑1‑25 EG330360 BINDHEADSCREW 3x6ZMC2‑BL
* 2‑1‑26 EP600190 BINDHEADB‑TITESCREW 3x8ZMC2‑BL
2‑1‑27 VG893800 BINDHEADP‑TITESCREW 2x6ZMC2‑BL
2‑1‑28 VE529700 PWHEADB‑TITESCREW 3x6‑8MFC2‑BL
* 2‑2 V6601400 P.C.B.ASS'Y OPERATION
* 2‑8 MF114250 FLEXIBLEFLATCABLEC&C 14P250mm
* 2‑11 V6065700 SUBCHASSIS
* 2‑12 V6065500 SUPPORT/PJ
* 2‑13 V6068900 BUTTONCASEASSY UPPER BL
* 2‑13 V6069000 BUTTONCASEASSY UPPER GD
* 2‑13 V6078100 BUTTONCASEASSY UPPER TI
* 2‑14 V6069100 BUTTON/POWER BL
* 2‑14 V6078900 BUTTON/POWER TI
* 2‑14 V6069200 BUTTON/POWER GD
* 2‑18 V6065600 SUPPORT/ENC
* 2‑19 V6071000 SUPPORT/SHAFT
* 2‑21 EP600190 BINDHEADB‑TITESCREW 3x8ZMC2‑BL
2‑22 EP600130 BINDHEADB‑TITESCREW 3x6ZMC2‑Y
2‑23 VN413300 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2‑BL
4‑1 V3316600 DCBRUSHLESSFAN 2410ML‑05W‑B40‑T14
* 4‑2 VV691100 FRAME SF
* 4‑4 VV713600 BRACKET F
* 4‑6 VZ012900 CUSHION,FAN
* 4‑8 CB502030 BINDINGTIE S‑75B
4‑10 EP630220 BINDHEADP‑TITESCREW 3x8ZMC2‑BL
4‑12 VV220300 BINDHEADB‑TITESCREW 3x30MFZN2‑BL
* 5‑1 V6228000 HEATSINK 40BS300‑L130
Z 5‑2 VY705000 TRANSISTOR 2SC5200R,O Q54,Q58,Q61,Q65
Z * 5‑3 V6063900 TRANSISTOR 2SC5358O,R Q68,Q72,Q75,Q79
Q82,Q86,Q89,Q93
5‑5 VK196000 SHEET 22x29
* 5‑6 V6492000 RADIATIONSHEET BFG‑20ADH‑624X36
5‑7 VK195900 SHEET 19x24
5‑9 VK173200 SCREW,TRANSISTOR 3x15SPFCM3
* 5‑13 VU195800 DAMPER,FIN
* 11 V6600100 P.C.B.ASS'Y DSP (RT)
* 11 V6600200 P.C.B.ASS'Y DSP (BG)
* 12 V6602700 P.C.B.ASS'Y FAMP (RT)
* 12 V6602800 P.C.B.ASS'Y FAMP (B)
* 12 V6602900 P.C.B.ASS'Y FAMP (G)
* 14 V6604100 P.C.B.ASS'Y MAIN (RT)
* 14 V6604700 P.C.B.ASS'Y MAIN (BG)
* 15 V6605500 P.C.B.ASS'Y FUNCTION (RT)
* 15 V6605600 P.C.B.ASS'Y FUNCTION (BG)
* 16 V6606400 P.C.B.ASS'Y VIDEO (RT)
* 16 V6606500 P.C.B.ASS'Y VIDEO (BG)
Z * 23 XZ445A00 POWERTRANSFORMER (BG)
Z * 23 XZ443A00 POWERTRANSFORMER (RT)
Z 23‑1 Vi449800 VOLTAGESELECTOR ESE‑37284‑F (RT)
Z 24 VU411300 POWERCORDASS'Y (B)
Z 24 VZ542500 POWERCORDASS'Y (RT)
25 V2438700 CORDSTOPPER 10P1 (RBT)
* 30 MF129100 FLEXIBLEFLATCABLE 29P100mmP=1.25
