Yamaha DSP-AX2 Service Manual

DSP-AX2
101 102
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
32 MF112100 FLEXIBLEFLATCABLE 12P100mmP=1.25
* 33 V6684100 SFLEXIBLEFLATCABLE 15P350mmP=1.25
* 34 MF111400 FLEXIBLEFLATCABLE 11P400mm
* 35 MF117140 FLEXIBLEFLATCABLE 17P140mmP=1.25
* 36 MF115060 FLEXIBLEFLATCABLE 15P60mmP=1.25
38 MF119200 FLEXIBLEFLATCABLE 19P200mm
* 51 V6404800 TOPCOVER GD
51 VZ617400 TOPCOVER BL
51 VZ617500 TOPCOVER TI
52 VJ893400 BOTTOMCOVER
* 54 V2614300 FRAME L
* 55 V6063400 FRAME R/LOWER
56 V2614500 FRAME SL
* 57 VZ618100 FRAME R/UP
* 58 V6063300 FRAME,CENTER
* 59 V6064400 REARPANEL (RT)
* 59 V6064500 REARPANEL (B)
* 59 V6064600 REARPANEL (G)
60 VV826100 SUPPORT TR
* 61 V6064700 SHIELDCASE
* 62 V6064900 SUPPORT D/PCB
* 63 V6669900 SSUPPORT,TOP
* 64 V6068000 KNOB/D43 BL
* 64 V6068100 KNOB/D43 GD
* 64 V6077800 KNOBD43 TI
* 65 V6001600 KNOBD15 BL
* 65 V6001700 KNOBD15 GD
* 65 V6001800 KNOBD15 TI
* 66 V6069800 KNOBD15 BL
* 66 V6069900 KNOBD15 GD
* 66 V6078400 KNOB/D15 TI
* 67 V6078600 KNOB/D15 BL
* 67 V6078700 KNOB/D15 TI
* 67 V6078800 KNOB/D15 GD
* 70 VJ895500 FRAME A
* 71 VT999700 SUPPORT R/FR
73 VE222600 CUSHION
80 V0042500 LEG D60xH21 GD
80 VS025000 LEG D60xH21 BL,TI
* 81 CB068880 PLASTICRIVET No.1027 (RBGT)
* 82 CB605620 PLASTICRIVET No.1781
* 83 VV692400 SUPPORT H/PCB
* 84 V6064800 SUPPORT SF
85 VN413300 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2‑BL
* 86 EP600190 BINDHEADB‑TITESCREW 3x8ZMC2‑BL
* 87 EG330360 BINDHEADSCREW 3x6ZMC2‑BL (RT)
* 88 VQ541700 BWHEADB‑TITESCREW 3x8‑8FCM3‑CU
89 VK625000 CUPS‑TITESCREW 5x10‑12ZMC2‑Y
90 21991500 PWHEADS‑TITESCREW 4x8‑10FCRM3‑BL BL
90 VD069600 PWHEADS‑TITESCREW 4x8‑10MFNI‑33 GD
90 VH313200 BWHEADS‑TITESCREW 4x8‑10FNM3‑BL TI
91 AA627310 GROUNDTERMINAL
* 92 03765560 PLAINWASHER 3.6x10x0.8FNM3‑3G
* 93 EP600220 BINDHEADB‑TITESCREW 3x10ZMC2‑Y
94 VK522000 SPECIALSCREWS‑TITE 4x8‑10FCRM3‑BL BL
94 VK522100 SPECIALSCREWS‑TITE 4x8‑10FNM3‑BL TI
94 VZ893000 DECORATEDSCREWS‑TIGHT 4x8‑10MFNI‑33 GD
* 96 VY979800 SUPPORT,FANCOVER
* 97 VY980000 SUPPORT/R
* 98 VY980100 PLATE,FANCOVER (RBGT)
99 VQ199500 DAMPER TRANSF. (RBGT)
100 VK173200 SCREW,TRANSISTOR 3x15SPFCM3
* 101 CB502030 BINDINGTIE S‑75B
* 102 V6983800 SPACER/T05
* 103 VQ758300 CUSHION,L
* 104 V6276700 CUSHION/F
* 105 VB072700 FLATHEADS‑TITESCREW 3x8ZMC2‑BL
121 VY731200 BONDINGHEADTAPPINGSCREW 3x10MFNI33
123 VK697600 BINDHEADB‑TITESCREW 3x10SPZMC2‑Y
124 EP600530 BINDHEADS‑TITESCREW 3x8ZMC2‑BL (RBGT)
* 135 EL300690 PWHEADP‑TITESCREW 3x8‑8MFZN2‑BL
* 151 V3768900 SCREW,LOCK 17L‑003C41
ACCESSORIES
* 200 V6283400 REMOTECONTROLTRANSMITTER RAV221
200‑1 AAX20900 BATTERYCOVER 103RRC‑170‑02R
200‑2 AAX20890 SLIDECOVER 103RRC‑171‑02R
Z * 203 V6545900 POWERCORDASS'Y INLET2.0m (G)
* 204 V6181600 SHEET/SIDER 1pc BL
* 204 V6181700 SHEET/SIDER 1pc TI
* 204 V6181800 SHEET/SIDER 1pc GD
* 205 V6181900 SHEET/SIDEL 1pc BL
* 205 V6182000 SHEET/SIDEL 1pc TI
* 205 V6182100 SHEET/SIDEL 1pc GD
BATTERY(ALKALINEDRY) 1.5VLR6(3S)AG
