RX-V361/HTR-6030/DSP-AX361
36
RX-V361/HTR-6030/
DSP-AX361
17. SOFTSWITCH17. SOFT SWITCH
P.C.B.上の機能設定をソフト的に切り替えて、本機を
動作させる機能です。
プロテクション機能は、P.C.B.の設定に従います。
※ 開発用メニューのため、詳細に関しては記載できま
せん。
This menu is used to switch the function settings on
P.C.B. through the software to activate the main unit.
The protection function follows the P.C.B. settings.
* As this is a development menu, it is not possible to
describe the details.
注） 開発用メニューのため、機能設定の変更は行わな
いでください。
機能設定を変更した場合、正常に動作しないこと
があります。
Note) As this is a development menu, do not change
the function setting.
Changing the function setting may hinder the
proper operation.
Switch mode
Model
Destination
Tuner destination
VIDEO format
AAC
OSD
YPAO
RDS
XM
DAB
USB
DOCK (iPod)
17.MODE:PCB
17.MODEL:361
17.DEST : UC
17.TUNER: UC
17.VIDEO:NTSC
17.AAC : NOT
17.OSD : NOT
17.YPAO: NOT
17.RDS : NOT
17.XM : NOT
17.DAB : NOT
17.USB : NOT
17.DOCK: NOT

Yamaha DSP-AX361 Specifications

General

Type	AV Receiver
Channels	5.1
Surround Sound Formats	Dolby Digital, DTS
Weight	9.5 kg
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV / 47 kΩ
Signal-to-Noise Ratio	100dB
Input Impedance	47k ohms
Video Inputs	4
Video Outputs	1
Audio Inputs	5 (Analog)
Audio Outputs	Analog: 2
Dimensions (W x H x D)	435 x 151 x 373 mm
Video Inputs/Outputs (Composite)	4/1
Audio Inputs/Outputs (Analog)	5/2
Audio Inputs/Outputs (Optical)	2/0
Audio Inputs/Outputs (Coaxial)	2/0
Power Output per Channel	100W (8 ohms, 20Hz-20kHz, 0.09% THD)
Total Harmonic Distortion (THD)	0.09%
