Yamaha DSP-AX430 User Manual

RX-V530/RX-V530RDS/HTR-5550/HTR-5550RDS/DSP-AX530
RX-V430/RX-V430RDS/HTR-5540/HTR-5540RDS/DSP-AX430
15
RX-V530/RX-V530RDS/HTR-5550/HTR-5550RDS/DSP-AX530
RX-V430/RX-V430RDS/HTR-5540/HTR-5540RDS/DSP-AX430
Dimensions/寸法 (W x H x D)
RX-V530/RX-V530RDS/HTR-5550/HTR-5550RDS/DSP-AX530/
RX-V430RDS/HTR-5540RDS
...................... 435 x 151 x 387 mm (17-1/8" x 5-15/16" x 15-1/4")
RX-V430/HTR-5540/DSP-AX430
.................. 435 x 151 x 380 mm (17-1/8" x 5-15/16" x 14-15/16")
Weight/重量
.................................................................... 10.0 kg (22 lbs. 1 oz.)
Finish/仕上げ
RX-V530/RX-V430 ................ Gold color (L, R, T, K) models
Black color (U, C, A, R) models
RX-V530RDS/RX-V430RDS ... Gold color (G) model
Black color (B, G) models
Titan color (B, G) models
HTR-5550/HTR-5540 ............ Gold color (T, K) models
Black color (U, C, A) models
Titan color (U, C) models
HTR-5550RDS/HTR-5540RDS .. Black color (G) model
Titan color (B, G) models
DSP-AX530/DSP-AX430 ...... Gold color (J) model
Accessories/付属品
Remote Control, Batteries (Manganese Dry), Indoor FM Antenna,
AM Loop Antenna, PAL 75/300 Socket [B model], Video Pin Cable
[U, C, A models]
* Specifications are subject to change without notice due to product
improvements.
 
U .......... U.S.A. model C ...... Canadian model
A .......... Australian model B ...... British model
G .......... European model L ....... Singapore model
R .......... General model T ....... Chinese model
K .......... Korean model J ....... Japanese model
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of
Dolby Laboratories.


 
“DTS” and “DTS Digital Surround” are registered trademarks of
Digital Theater Systems, Inc.


• Set Menu Table/セットメニュー
No. MAIN MENU
SUB MENU: PRESET VALUE
SETTING RANGES
RX-V530/RX-V530RDS/HTR-5550/ RX-V430/RX-V430RDS/HTR-5540/
HTR-5550RDS/DSP-AX530 HTR-5540RDS/DSP-AX430
1. SPEAKER SET
1A. CENTER SP: LARGE 1A. CENTER SP: LARGE LARGE, SMALL, NONE
1B. MAIN SP: LARGE 1B. MAIN SP: LARGE LARGE, SMALL
1C. REAR L/R SP: LARGE 1C. REAR L/R SP: LARGE LARGE, SMALL, NONE
1D. LFE/BASS OUT: BOTH 1D. LFE/BASS OUT: BOTH SW, MAIN, BOTH
1E. MAIN LEVEL: NORMAL 1E. MAIN LEVEL: NORMAL NORMAL, –10dB
2. LFE LEVEL SP LFE LEVEL: 0dB SP LFE LEVEL: 0dB –20dB — 0dB (1dB step)
HP LFE LEVEL: 0dB HP LFE LEVEL: 0dB –20dB — 0dB (1dB step)
3. SP DELAY TIME CENTER DELAY: 0ms CENTER DELAY: 0ms 0ms — 5ms (1ms step)
4. DYNAMIC RANGE SP DYNAMIC RANGE: MAX SP DYNAMIC RANGE: MAX MAX, STD, MIN
HP DYNAMIC RANGE: MAX HP DYNAMIC RANGE: MAX MAX, STD, MIN
5. L/R BALANCE CENTER CENTER L, ••• , CENTER, ••• , R (40 steps)
6. HP TONE CONTROL HP BASS: 0dB HP BASS: 0dB –6dB — +3dB (1dB step)
HP TREBLE: 0dB HP TREBLE: 0dB –6dB — +3dB (1dB step)
7. I/O ASSIGNING
7A [A]. CV INPUT 1: DVD – DVD
7A [B]. CV INPUT 2: D-TV/CBL – D-TV/CBL
7B (1). OPTICAL OUT 1: MD/CD-R – MD/CD-R
7C (2). OPTICAL IN 1: MD/CD-R – MD/CD-R
7C (3). OPTICAL IN 2: DVD 7C (1). OPTICAL IN 1: DVD DVD
7C (4). OPTICAL IN 3: D-TV/CBL – D-TV/CBL
7D (5). COAXIAL IN 1: CD 7C (2). COAXIAL IN 1: CD CD
8. INPUT MODE AUTO AUTO AUTO/LAST
9. DISPLAY SET DIMMER: 0 DIMMER: 0 –4 — 0 (1 step)
10. MEMORY GUARD OFF OFF OFF/ON
11. DUAL MONO MAIN MAIN MAIN, SUB, ALL
