Yamaha DSP-AX463 - Self-Diagnostic: Multi-Channel Input (XCH)

30
RX-V463/HTR-6140/DSP-AX463
RX-V463/HTR-6140/
DSP-AX463
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: DVD ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
Both ch, -20 dBm
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
+6.0 dB
FRONT
+11.5 dBm
+11.5 dBm
+11.5 dBm
+14.5 dBm
+8.5 dBm
CENTER
-∞
-∞
-∞
-∞
-∞
SURROUND
-∞
-∞
-∞
-∞
-∞
-3.5 dBm
-∞
-∞
-∞
-∞
Sub-menu
D. XCH INPUT
The input source [MULTI CHANNEL INPUT] is
selected.
It is possible to select the 6-ohm/8-ohm by using
the sub-menu.
6 ch INPUT 6-ohm
D1.6chINPUT 6 Ω
D2.8chINPUT 6 Ω
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
+11.5 dBm
SURROUND
+11.5 dBm -3.5 dBm
Sub-menu
8 ch INPUT 6-ohm
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
+11.5 dBm
SURROUND
+11.5 dBm -3.5 dBm
Sub-menu
D. XCH INPUT
入力ソース［MULTICHANNELINPUT］が選択さ
れます。
サブメニューにより、6オーム／8オームが選択可
能です。
6chINPUT6-ohm
8chINPUT6-ohm
D3.6chINPUT 8 Ω
6 ch INPUT 8-ohm
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: MULTI CH INPUT
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
+11.5 dBm
SURROUND
+11.5 dBm -3.5 dBm
Sub-menu
6chINPUT8-ohm
FRONT : SML 0dB
CENTER : NONE
LFE/B : FRNT
TONE : MAX
TONE : MIN
6 ch INPUT 6-ohm
6 ch INPUT 8-ohm
6 ch INPUT 8-ohm
