35
English
INTRODUCTION
PREPARATION
BASIC OPERA-
TION
ADVANCED
OPERATION
ADDITIONAL
INFORMATION
APPENDIX
SET MENU
3 HP TONE CTRL (headphone
tone control)
Use this feature to adjust the level of the bass and treble
when you use your headphones.
Control range (dB): 6 to +3
Initial setting: 0 dB for both BASS and TRBL (treble)
4 I/O ASSIGNMENT
It is possible to assign jacks according to the component
to be used if this units COMPONENT VIDEO input jack
or DIGITAL INPUT/OUTPUT jack settings (component
names for jacks) differ from that component. This makes
it possible to change the jack assignment and effectively
connect more component.
Once you assign, you can select that component with
INPUT l / h (or the input selector buttons).
4A CMPNT-V INPUT (for the
COMPONENT VIDEO jacks)
Initial settings: [A] DVD
[B] D-TV/CBL
4B OPTICAL OUT (for the
OPTICAL OUTPUT jack)
Initial setting: (1) MD/CD-R
4C OPTICAL IN (for the OPTICAL
INPUT jacks)
Initial settings: (2) MD/CD-R
(3) DVD
(4) D-TV/CBL
4D COAXIAL IN (for the COAXIAL
INPUT jack)
Initial setting: (5) CD
Note
You cannot select an item more than once for the same type of
jack.
5 INPUT MODE (initial input
mode)
Use this feature to designate the input mode when turning
on the power of this unit with the source component
connected to more than one type of input jacks.
Choices: AUTO, LAST
Initial setting: AUTO
AUTO
Select this to allow this unit to automatically detect the
type of input signal and select the appropriate input mode.
LAST
Select this to set this unit to automatically select the last
input mode used for that source.
3 HP TONE CTRL
BASS
TRBL
+
0dB
4A CMPNT-V INPUT
[B] D-TV/CBL
[A] DVD
4B OPTICAL OUT
(1) MD/CD-R
4C OPTICAL IN
(2) MD/CD-R
(4) D-TV/CBL
(3) DVD
4D COAXIAL IN
(5) CD
5 INPUT MODE
AUTO LAST
: Exit
/
/+ : Select
0107AX620(GB)_31-39_EN 1/23/1, 9:27 AM35
