Yamaha DSP-AZ1 User Manual

E-105
APPENDIX
English
CINEMA EQ FREQUENCY CHARACTERISTICS
■ L, C, R preset value
HIGH: FRQ 12.7 kHz/GAIN –3 dB
PEQ: FRQ 12.7 kHz/GAIN –4 dB
■ FRONT and REAR preset value
HIGH: FRQ 12.7 kHz/GAIN 0 dB
PEQ: FRQ 8.0 kHz/GAIN –3 dB
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
PEQ
HIGH
HIGH
+
PEQ
GAIN
FRQ
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
PEQ
HIGH
GAIN
FRQ
■ HIGH frequency
FRQ 1.0 kHz/GAIN +6 – –9 dB
FRQ 1.0 – 12.7 kHz/GAIN +6/–9 dB
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
GAIN
FRQ
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
1.0k
1.2k
1.6k
2.0k
2.5k
3.2k
4.0k
5.0k
5.7k
6.3k
7.1k
8.0k
9.0k
10.1k
11.3k
12.7kHz
GAIN
FRQ
■ PEQ frequency
FRQ 1.0 kHz/GAIN +6 – –9 dB/Q 1.85 (fixed) FRQ 1.0 – 12.7 kHz/GAIN +6/–9 dB/Q 1.85 (fixed)
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
GAIN
FRQ
+6
+3
0
–3
–6
–9
20 50 100 200 500 1k 2k 5k 10k 20k
1.0k
1.2k
1.6k
2.0k
2.5k
3.2k
4.0k
5.0k
5.7k
6.3k
7.1k
8.0k
9.0k
10.1k
11.3k
12.7kHz
GAIN
FRQ
