E-35
PREPARATIONS
English
SPEAKER MODE SETTINGS
■ 1A CENTER SP (center speaker mode)
By adding a center speaker to your speaker configuration, this unit can provide good dialogue localization for many listeners and superior
synchronization of sound and images. The OSD shows a large, small, or no center speaker depending on how you set this item. The initial
setting is “LRG”.
LRG: Select the “LRG” (Large) setting if you have a large center speaker. The entire range of center channel signals is sent to the center
speaker.
SML: Select the “SML” (Small) setting if you have a small center speaker. Center channel low frequency signals of 90 Hz and below
are directed to the speakers selected with the “1E LFE/BASS OUT” item.
NONE: Select the “NONE” setting if you do not have a center speaker. All of the center channel signals are directed to the left and right
main speakers.
■ 1B MAIN SP (main speaker mode)
The display shows small or large main speakers depending on how you set this item. The initial setting is “LARGE”.
LARGE: Select the “LARGE” setting if you have large main speakers. The entire range of left and right main channel signals is directed to
the left and right main speakers.
SMALL: Select the “SMALL” setting if you have small main speakers. The main channel low frequency signals of 90 Hz and below are
directed to the speakers selected with the “1E LFE/BASS OUT” item.
Caution
• When you select the “MAIN” setting for the “1E LFE/BASS OUT” item, the main channel low frequency signals of 90 Hz and below are
directed to the main speakers even if you select the “SMALL” setting for the main speaker mode.
“LRG SML NONE
1A CENTER SP
LRG “SML NONE
1A CENTER SP
LRG SML “NONE
1A CENTER SP
“LARGE SMALL
1B MAIN SP
LARGE “SMALL
1B MAIN SP
To Next Page
