Yamaha DSP-E800 - No.5 SPEAKERS SET; Sub-menu descriptions

DSP-E800
DSP-E800
13
1 MAIN:SML 0DB 7D-07 LARGE LARGE SMALL 0dB SWFR L R NONE NONE NONE L+R
2 MAIN:LRG 0DB 7D-08 LARGE LARGE LARGE 0dB SWFR L R NONE NONR NONE NONE
3 MAIN:LRG -10 7D-09 LARGE LARGE LARGE -10dB SWFR L R NONE NONE NONE NONE
4 B:MAIN C:NONE 7D-0A NONE LARGE LARGE 0dB MAIN L R NONE NONE NONE NONE
5 LFE/B:MAIN 7D-0B LARGE LARGE LARGE 0dB MAIN
LFE+FL LFE+FR C NONE NONE NONE
6 LFE/B:SWFR 7D-1A LARGE LARGE LARGE 0dB SWFR NONE NONE NONE NONE NONE LFE
7 C:NONE 7D-51 NONE LARGE LARGE 0dB SWFR C+L C+R NONE NONE NONE LFE
8 C:S REAR:S – – – SMALL SMALL LARGE 0dB SWFR L+FL R+FR C RL RR
C+RL+RR+LFE
9 FRONT MIX 7D-57 LARGE LARGE LARGE 0dB SWFR FL FR NONE NONE NONE NONE
No.5 SPEAKERS SET
The input is automatically discriminated by signal detection and switched with priorities Coaxial>Optical>Analog.
The L/R signals are output to channels specified by the sub-menu without being processed.
There are the following nine sub-menus items. Signal routes of the sub-menu 1-4 are the same as EFFECT OFF.
But MAIN L/R are signals through the digital circuit.
Signal routes of the sub-menu 5-9 are the same as "2. YSS M" of "No. 2 DSP THROUGH".
However, only MAIN L/R is output in the sub-menu 1-4.
SUB MENU
CENTER SP
OUTPUTSETTING
LFE/BASS
MAIN
LEVEL
MAIN
L
MAIN
R
CENTER
REAR
L
REAR
R
SUB
WOOFER
MAIN SPREAR SP
REMOTE
CONTROL
CODE
SUB MENU DESCRIPTION
1 MAIN:SML 0DB Verification of the High and low pass filter response and gain in the bass redirection mode.
2 MAIN:LRG 0DB Reference of the sub menu No. 1 and 2.
3 MAIN:LRG -10 Verification of the effect in the main level function.
4 B:MAIN C:NONE Verification of the mixing circuit effect to the main channel.
5 LFE/B:MAIN Verification of the bass mix gain.
6 LFE/B:SWFR Verification of the LFE maximum output.
7 C:NONE Verification of the center mix gain.
8 C:S REAR:S Verification of the high and low pass filter response and gain in the bass redirection mode.
9 FRONT MIX Verification of the front mix gain.
LARGE: Mode in which speakers with high bass-sound playback capability (large unit) are used. Full-range signals present
on the channel are output from the speaker.
SMALL : Mode in which speakers with low bass-sound playback capability (small unit) are used. Low bass signals (below
90Hz) on the channel are mixed into the channel selected by the LFE/BASS setting.
NONE: Mode in which center speaker is not used. The center channel signal is reduced by 3 dB and mixed into MAIN L/R.
LFE/B:MAIN
: Mode in which subwoofer speaker is not used. The LFE channel signal is reduced by 4.5 dB and mixed into
MAIN L/R. But because of the phase difference, the MAIN L/R output is not simply summed.
The analog switches in each sub-menu are set as follows:
Description of the submenu as follows:
5. MA I N : SML 0 DB
5. B : MA I N C : NON
5. C : NONE
5. MA I N : LRG 0 DB
5. L FE / B : MAIN
5. C : S REAR : S
5. MA I N : LRG - 1 0
5. L FE / B : SWFR
5. FRONT M I X
