SETUP MENU
Speaker settings
DVD-A
DVD-V
When you adjust speakers while DISC DIRECT is
functioning, follow the procedures described below.
If you wish to enjoy multi-channel sound reproduction,
you need to select “Multi-channel” on the setup menu and
make following adjustments.
When you select “2-channel”, that is, when connecting to
only 2 speakers or a Dolby Pro Logic decoder, the
following adjustments are not necessary.
VIDEO 1
SHIFT
CODE SET
1
HALL
2
JAZZ
SETUP
3
ROCK
ANGLE
4
ENTERTAINMENT
MARKER
5
SPORTS
6
MONO MOVIE
PLAY MODE
7
MOVIE 1
REPEAT
8
MOVIE 2
A–B
DVD
CD
AMP
9
/DTS
TOP MENU
LEVEL
MENU
SET MENU
TEST
ON SCREEN
B. BOOST
RETURN
0
SELECT
>
–
10
MATRIX 6.1
GROUP
CANCEL
STEREO
PAGE
MUTE
VOL
ABCDE
ENTER
CH
PRESET
CH
PRESET
u, d, j, i
/ ENTER
(U.S.A. model)
SETUP
SELECT
ENTER RETURN
ms
ms
dB
0
dBdB
L
Exit
Test
LS
R
SW
C
RS
dB
0
0
0
0
0
Front (L)
Rear
(L) a
Subwoofer
(L) c b (R) c (R) a
Exit
Test signal
Center Front (R)
aab a c
b a
a Output mode
Change the settings of each speaker in accordance with
your speaker system.
1 Press the cursor buttons (u, d, j, i) to
select a speaker and press ENTER.
2 Press the cursor buttons (u, d) to select the
setting and press ENTER.
• Choices of the speaker size
L: Large, Small
R: Large, Small
C: Large, Small, None
SW: Used, Not used
LS: Large, Small, None
RS: Large, Small, None
The size of L is set to be the same as that of R.
Therefore, if you select Large for L, the size of R is
automatically set to Large. This also applies to the
sizes of LS and RS.
• Example: Rear left speaker
1 when the speaker is not used.
2 when using a large speaker capable of low-
frequency (under 100 Hz) output.
3 when using a small speaker that is not capable of
low-frequency output. (the included speakers,
NX-S100S etc.)
• Factory settings of the speaker sizes
L/R: Large
C/LS/RS: Large
SW: Used
LS
LS
123
