SPECIFICATIONS
AUDIO SECTION
• Minimum RMS Output Power
FRONT L/R, CENTER, REAR L/R
1 kHz, 0.9% THD, 6 Ω ........................................................ 33 W
[U.S.A. and Canada models]
20 Hz to 20 kHz, 0.9% THD, 6 Ω ..................................... 25 W
SUBWOOFER
100 Hz, 0.9% THD, 5 Ω ...................................................... 40 W
• Maximum Power (EIAJ)
FRONT L/R, CENTER, REAR L/R (1 kHz, 10% THD, 6 Ω)
............................................................................................ 40 W
SUBWOOFER (100 Hz, 10% THD, 5 Ω)
............................................................................................ 50 W
• Total Harmonic Distortion
FRONT L/R (20 W, 1 kHz) ................................................ 0.05 %
• Signal to Noise Ratio (IHF-A Network, shorted) .................... 95 dB
• Input Sensitivity
VIDEO 1, VIDEO 2, VCR, MD/CD-R .................. 200 mV/47 kΩ
• Output Level (when 200 mV is input.)
PRE OUT (FRONT L/R, CENTER, REAR L/R) ........... max. 1 V
PRE OUT (SUBWOOFER) ............................................ max. 4 V
REC OUT .............................................................. 200 mV/1.2 kΩ
Headphones ............................................................ 165 mV/100 Ω
VIDEO SECTION
• Video Signal Level
Video .......................................................................... 1 Vp-p/75 Ω
S Video (Y/C)
[U.S.A., Canada and General models] .... 1 Vp-p/0.286 Vp-p/75 Ω
[Australia, U.K. and Europe models] .......... 1 Vp-p/0.3 Vp-p/75 Ω
Component (Y/P
B
, P
R
)
[U.S.A., Canada, General and Australia models]
.................................................................. 1 Vp-p/0.7 Vp-p/75 Ω
Signal to Noise Ratio ............................................................ 50 dB
TUNER SECTION
• FM Tuning Range
[U.S.A. and Canada models] ............................ 87.5 to 107.9 MHz
[Other models] .................................................. 87.5 to 108.0 MHz
• AM Tuning Range
[U.S.A. and Canada models] ............................... 530 to 1710 kHz
[U.K., Europe and Australia models] .................. 531 to 1611 kHz
[General model] ................................... 530/531 to 1710/1611 kHz
SPEAKER SECTION
• Front and Rear Speakers
Model Name ................................................................. NX-S100S
Type ................................................................... 2-way Bass reflex
Speakers
............. 10 cm (4 inch) cone, 1.9 cm (3/4 inch) balanced dome,
magnetically shielded
Impedance ................................................................................ 6 Ω
• Center Speaker
Model Name ................................................................. NX-S100C
Type ................................................................... 2-way Bass reflex
Speakers .............. 7 cm (3 inch) cone x 3, 1.5 cm (5/8 inch) piezo,
magnetically shielded
Impedance ................................................................................ 6 Ω
• Subwoofer
Model Name .................................................................... SW-S100
Type ........ Advanced YAMAHA Active Servo Technology system
Speaker ............ 16 cm (6-1/2 inch) woofer, magnetically shielded
GENERAL
• Power Supply
[U.S.A. and Canada models] ............................... AC 120 V/60 Hz
[Australia model] ................................................. AC 240 V/50 Hz
[U.K. and Europe models] ................................... AC 230 V/50 Hz
[General model] ........................................... AC 220/240 V, 50 Hz
• Power Consumption
DVR-S100 ............................................................................. 40 W
SW-S100 .............................................................................. 160 W
• Standby Power Consumption
DVR-S100
[General model] .................................................................... 0.5 W
[Other models] ...................................................................... 0.4 W
• Laser pickup
Wave length ........................................................................ 665 nm
Laser power .................................................................... CLASS II
Laser output ........................................Max. 1.0 mW (Continuous)
Output value determined by 21 CFR CHAPTER1,
SUBCHAPTER J
• Dimensions (W x H x D)
DVR-S100 ....................................................... 435 x 84 x 360 mm
(17-1/8” x 3-3/8” x 14-3/16”)
SW-S100 ........................................................ 200 x 395 x 416 mm
(7-7/8” x 15-1/2” x 16-3/8”)
NX-S100C ....................................................... 440 x 85 x 122 mm
(17-3/8” x 3-3/8” x 4-7/16”)
NX-S100S ....................................................... 120 x 250 x 92 mm
(4-3/4” x 9-7/8” x 3-5/8”)
• Weight
DVR-S100 ............................................................................. 6.0kg
(13 lbs 4 oz)
SW-S100 .............................................................................. 10.7kg
(23 lbs 9 oz)
NX-S100C ............................................................................. 1.7kg
(3 lbs 12 oz)
NX-S100S ............................................................................. 1.1kg
(2 lbs 6 oz)
• Usable temperature range .............................................. 5°C to 35°C
• Usable humidity range
.......................... 5% to 90% (There should be no condensation.)
• Accessories .............................................................. Refer to page 3.
