E
4-15
EMU00370
INSPECTING FUEL FILTER
w
Gasoline (petrol) is highly flammable,
and its vapors are flammable and explo-
sive.
8 If you have any question about proper-
ly doing this procedure, consult your
Yamaha dealer.
8 Do not perform this procedure on a hot
or running engine. Allow the engine to
cool.
8 There will be fuel in the fuel filter. Keep
away from sparks, cigarettes, flames
or other sources of ignition.
8 This procedure will allow some fuel to
spill. Catch fuel in a rag. Wipe up any
spilled fuel immediately.
8 The fuel filter must be reassembled
carefully with O-ring, filter cup, and
hoses in place. Improper assembly or
replacement can result in a fuel leak,
which could result in a fire or explo-
sion hazard.
EMU00978
1) Remove the nut holding the fuel filter
assembly if equipped.
2) Unscrew the filter cup 1, catching any
spilled fuel in a rag.
3) Remove the filter element 2, and wash
it in solvent.
Allow it to dry. Inspect the filter element
and O-ring 3 to make sure they are in
good condition. Replace them if neces-
sary.
000983
q
w
e
r
