Yamaha E8D - Main Components Overview

E
2-1
EMU01206
MAIN COMPONENTS
!6
q
e
r
t
y
!0
!1
w
u
i
o
!4
!5
!2
!3
1 Recoil starter handle
2 Top cowling
3 Tiller handle
4 Throttle control grip
5 Choke knob
6 Engine stop button/Engine stop lanyard switch
7 Gear shift lever
8 Rope attachment
9 Tilt lock lever
0 Clamp screw
q Clamp bracket
w Trim angle adjusting rod
e Anti-cavitation plate
r Cooling water inlet
t Propeller
y Fuel tank
* May not be exactly as shown; also may not be
included as standard equipment on all
models.
