Yamaha F200A - Electrical Specifications; Ignition and Fuel System Specs

60L3D1X
18
Electrical
Item Unit
Model
F200AET FL200AET
Ignition and ignition control
system
Ignition timing
(engine idle speed) Degree TDC
Pulser coil output peak voltage
(W/R – B, W/B – B, W/G – B)
at cranking (unloaded) V 5.3
at cranking (loaded) V 5.3
at 1,500 r/min (loaded) V 20
at 3,500 r/min (loaded) V 43
Pulser coil resistance
(*1)
(W/R – B, W/B – B, W/G – B)
Ω
459–561
ECM output peak voltage
(B/O – B, B/Y – B, B/W – B)
at cranking (loaded) V 252
at 1,500 r/min (loaded) V 260
at 3,500 r/min (loaded) V 260
Spark plug gap mm (in) 1.1 (0.043)
Ignition coil resistance
Primary coil (R/Y – B/O,
R/Y – B/Y, R/Y – B/W)
Ω
1.5–1.9
Secondary coil
(spark plug wire –
spark plug wire)
k
Ω
19.6–35.4
Throttle position sensor output
voltage (P – B)
mV 695–705
Oil pressure sensor output
voltage (engine idle speed)
(O – B)
V3.8
Intake air temperature sensor
resistance
at 0 °C (32 °F) k
Ω
5.4–6.6
at 80 °C (176 °F) k
Ω
0.29–0.39
Engine temperature sensor
resistance (B/Y – B)
at 20 °C (68 °F) k
Ω
54.2–69.0
at 100 °C (212 °F) k
Ω
3.12–3.48
Thermoswitch continuity
temperature (P – B)
ON °C (°F) 84–90 (183–194)
OFF °C (°F) 68–82 (154–179)
(*1)
The figures are for reference only.
Maintenance specifications
