Yamaha F200A - Wiring Diagrams; Wiring Diagram Overview and Legend

Wiring diagram
F200AET, FL200AET
1 Low-pressure fuel pump
2 Low-pressure fuel pump driver
3 High-pressure fuel pump relay
4 High-pressure fuel pump
5 Idle speed control
6 Fuel injector
7 Spark plug
8 Ignition coil
9 Intake air pressure sensor
0 Thermoswitch
A Engine temperature sensor
B Pulser coil
C Stator coil
D Rectifier Regulator
E Throttle position sensor
F Shift cut switch
G Neutral switch
H ECM
I Fuse (5 A)
J Fuse (30 A)
K Fuse (20 A)
L Starter relay
M Starter motor
N Power trim and tilt relay
O Power trim and tilt motor
P Trim sensor
Q Battery
R Intake air temperature sensor
S Main relay
T Oil pressure sensor
U Power trim and tilt switch
È To warning indicator
É To remote control
Ê To trim meter
Ë To computer
Ì To diagnostic indicator
Color code
B: Black
Br : Brown
G: Green
Gy : Gray
L: Blue
Lg : Light green
O : Orange
P: Pink
R: Red
Sb : Sky blue
W: White
Y : Yellow
B/O : Black/orange
B/W : Black/white
B/Y : Black/yellow
Br/W : Brown/white
G/B : Green/black
G/R : Green/red
G/W : Green/white
G/Y : Green/yellow
L/R : Blue/red
L/W : Blue/white
L/Y : Blue/yellow
O/B : Orange/black
O/R : Orange/red
O/Y : Orange/yellow
P/B : Pink/black
P/G : Pink/green
P/W : Pink/white
R/B : Red/black
R/Y : Red/yellow
W/B : White/black
W/G : White/green
W/R : White/red
Y/G : Yellow/green
