Yamaha F200A - Power Trim and Tilt Unit Service; Assembling the Gear Pump

60L3D1X
30
Power trim and tilt unit
7
Assembling the gear pump
1. Install the drive gears
1
, dowel pins
2
,
balls
3
, and shuttle pistons
4
into the
gear housing 1
5
.
2. Install the gear housing 2
6
.
3. Install the balls
7
, manual release spring
8
, and bracket
9
by installing the bolts
0
, then tightening them to the specified
torque.
4. Install the relief valve seal
A
and ball
B
into the gear housing 1
5
.
5. Install the filters
C
and gear pump
D
by
installing the bolts
E
, then tightening
them to the specified torque.
6. Install the manual valve
F
.
T
R
.
.
Gear pump bracket bolt
0
:
7 N·m (0.7 kgf·m, 5.1 ft·lb)
T
R
.
.
Up-relief lock screw
a
height
(from the top of the gear housing):
1.8–2.0 mm (0.071–0.079 in)
Down-relief lock screw
b
depth
(from the top of the gear housing):
1.5–2.0 mm (0.059–0.079 in)
T
R
.
.
Gear pump bolt
E
:
7 N·m (0.7 kgf·m, 5.1 ft·lb)
Maintenance interval chart / Power trim and tilt unit
