SPEC
Specifications
17
60L3D1X
Lower unit
Oil pump
Discharge
at 97–103 °C (207–217 °F)
with 10W-40 engine oil
L (US gal,
Imp gal)/min
at 700 r/min
8.8 (2.32, 1.94)
Pressure kPa
(kgf/cm
2
, psi)
138 (1.38, 19.62)
Relief valve opening pressure kPa
(kgf/cm
2
, psi)
529–647 (5.29–6.47, 75.22–92.00)
Thermostats
Opening temperature °C (°F) 60 (140)
Fully open temperature °C (°F) 70 (158)
Valve open lower limit mm (in) 4.3 (0.17)
Engine speed
Engine idle speed r/min 650–750
Item Unit
Model
F200AET FL200AET
Gear backlash
Pinion-to-forward gear mm (in) 0.21–0.44
(0.008–0.017)
0.35–0.70
(0.014–0.028)
Pinion-to-reverse gear mm (in) 0.70–1.03
(0.028–0.041)
0.70–1.03
(0.028–0.041)
Pinion shims mm 0.10, 0.12, 0.15, 0.18, 0.30, 0.40, 0.50
Forward gear shims mm 0.10, 0.12, 0.15, 0.18, 0.30, 0.40, 0.50
Reverse gear shims mm 0.10, 0.12, 0.15, 0.18, 0.30, 0.40, 0.50
Propeller shaft shims mm — 0.10, 0.12, 0.15, 0.18,
0.30, 0.40, 0.50
Item Unit
Model
F200AET FL200AET
