Yamaha F25D - Components; Components Diagram

16
Components
EMU2579T
Components diagram
TIP:
* May not be exactly as shown; also may not be included as standard equipment on all mod-
els (order from dealer).
F25DET, FT25FET
1
2
10
3
5
6
7
8
12
13
11
15
4
14
9
ZMU06595
1. Top cowling
2. Cowling lock lever(s)
3. Idle hole
4. Drain screw
5. Anti-cavitation plate
6. Trim tab
7. Propeller
8. Cooling water inlet
9. Clamp bracket
10. Power trim and tilt switch
11. Alert indicator
12. Tilt support knob
13. Flushing device
14. Remote control box (side mount type)*
15. Fuel tank
