Operation
52
4. Pull up the shallow water lever (if
equipped).
5. Hold the rear of the top cowling with one
hand and tilt the engine up fully.
6. Push the tilt support knob into the clamp
bracket. Or the tilt support bar will turn to
the lock position automatically. NO-
TICE: Do not use the tilt support lever
or knob when trailering the boat. The
outboard motor could shake loose
from the tilt support and fall. If the
motor cannot be trailered in the nor-
mal running position, use an addi-
tional support device to secure it in
the tilt position. For more detailed in-
formation, see page 58.
[ECM01641]
EMU32724
Procedure for tilting up (power trim
and tilt models)
1. Place the remote control lever / gear
shift lever in neutral.
2. Press the power trim and tilt switch “ ”
(up) until the outboard motor has tilted
up completely.
