Operation
55
EMU32741
Procedure
1. Place the gear shift lever in neutral.
2. Place the tilt lock lever in the release/up
position.
3. Slightly tilt the outboard motor up. The
tilt support bar will lock automatically,
supporting the outboard motor in a par-
tially raised position. This outboard mo-
tor has 2 positions for shallow water
cruising.
4. To return the outboard motor to the nor-
mal running position, place the gear shift
lever in neutral.
5. Place the tilt lock lever in the lock/down
position, then slightly tilt the outboard
motor up until the tilt support bar auto-
matically returns to the free position.
6. Slowly lower the outboard motor to the
normal position.
EMU32851
Power trim and tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
ECM00260
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
