EAA00090
FJR1300(R)/FJR1300A(R) 2003
SETUP AND PREDELIVERY CHECKLIST
NOTE:
_
Check the following items again after setup and predelivery service have been completed.
A: INSTALLATION OF THE PARTS INCLUDED IN THE CRATE
à HANDLEBAR à BATTERY LEADS
à GRIP ENDS à FRONT LEFT INNER PANEL (FRONT COWLING)
Ã
FRONT WHEEL
Ã
FRONT RIGHT INNER PANEL (FRONT COWLING)
Ã
FRONT FENDER
Ã
RIGHT INNER PANEL (FRONT COWLING)
Ã
FRONT BRAKE HOSE HOLDERS
Ã
WINDSHIELD
Ã
REAR VIEW MIRRORS
Ã
U-LOCK BAND
B: TIGHTENING TORQUE OF EACH PART
Ã
Steering stem nut 115 Nm (11.5 m • kg)
à Hexagon socket bolt (grip end) 4.0 Nm (0.4 m • kg)
Ã
Wheel axle 72 Nm (7.2 m • kg)
Ã
Axle pinch bolt 23 Nm (2.3 m • kg)
à Nut (reflector) (for AUS only) 4.0 Nm (0.4 m • kg)
Ã
Flange bolt (brake caliper) 40 Nm (4.0 m • kg)
Ã
Flange bolt (front wheel sensor) (FJR1300A) 30 Nm (3.0 m • kg)
Ã
Screw (front fender) 6.0 Nm (0.6 m • kg)
Ã
Flange bolt (front brake hose holder) 7.0 Nm (0.7 m • kg)
C: ROUTING OF WIRE, CABLES, ETC.
Ã
Clutch hose
Ã
Positive battery lead
Ã
Brake hose
Ã
Negative battery lead
D: ADJUSTMENTS
Ã
CHECKING THE ENGINE OIL LEVEL
Ã
BLEEDING THE HYDRAULIC BRAKE SYSTEM
Ã
CHECKING THE FINAL DRIVE OIL LEVEL
Ã
ADJUSTING THE CLUTCH LEVER
Ã
CHECKING THE COOLANT LEVEL
Ã
CHECKING THE CLUTCH FLUID LEVEL
Ã
ADJUSTING THE ENGINE IDLING SPEED
Ã
BLEEDING THE HYDRAULIC CLUTCH SYSTEM
Ã
ADJUSTING THE THROTTLE CABLE FREE
PLAY
Ã
ADJUSTING THE FRONT FORK LEGS
à ADJUSTING THE REAR SHOCK ABSORBER AS-
SEMBLY
à ADJUSTING THE FRONT BRAKE
à ADJUSTING THE REAR BRAKE à ADJUSTING THE HEADLIGHT BEAMS
à ADJUSTING THE REAR BRAKE LIGHT SWITCH à CHECKING AND CHARGING THE BATTERY
à CHECKING THE BRAKE FLUID LEVEL
E: FUNCTION AND PERFORMANCE
à Check the function of the headlights, meter lights,
and taillight
à Check the function of the indicator on the speedom-
eter
à Check the function of the brake light à Check the feel of the brakes
à Check the function of the turn signals and indicator
lights
à Check engine for irregular noise (Yes/ No)
à Check for exhaust leaks (Yes/ No)
Ã
Check the tone quality of the horn
F: ACCESSORIES, ETC. FOR DELIVERY
Ã
Owner’s manual
Ã
Locks
Ã
Owner’s tool kit
