–69–
EAA10300
TIGHTENING TORQUE
Part to be tightened Thread size
Tightening torque
Nm m • kg
Engine:
Spark plug M10 13 1.3
Engine oil drain plug M14 43 4.3
Chassis:
Engine mounting:
Rear lower mounting bolt M10 45 4.5
Spacer bolt M16 18 1.8
Rear upper mounting bolt and nut M10 45 4.5
Front mounting bolt M12 55 5.5
Pinch bolt M8 24 2.4
Bolt (engine bracket 1 and frame) M10 32 3.2
Bolt (engine bracket 1 and engine) M8 16 1.6
Bolt (engine bracket 2 and engine) M10 36 3.6
Bolt (engine bracket 2 and frame) M8 16 1.6
Fuel tank and frame M6 10 1.0
Fuel tank and fuel tank bracket M8 15 1.5
Front wheel axle M18 72 7.2
Front wheel axle pinch bolt M8 23 2.3
Brake disc and wheel M6 18 1.8
Front brake caliper M10 40 4.0
Front brake hose holder and front fork M6 7 0.7
Brake caliper bleed screw M8 6 0.6
Front wheel sensor and sensor housing
(FJR1300A)
M8 30 3.0
Front brake pipe (hydraulic unit to front brake cali-
per) and lower bracket (FJR1300A)
M6 7 0.7
Front brake hose (hydraulic unit to front brake cali-
per) holder and front wheel sensor holder on lower
bracket (FJR1300A)
M6 7 0.7
Front wheel sensor lead holder and lower bracket
(FJR1300A)
M6 7 0.7
Front brake pipe union bolt (FJR1300A) M8 30 3.0
Reflector (for AUS only) M6 4 0.4
Rear wheel axle nut M18 125 12.5
Rear wheel axle pinch bolt M8 16 1.6
Brake torque rod M8 30 3.0
Rear brake caliper retaining bolt M10 27 2.7
Brake fluid reservoir cap M40 2 0.2
Brake hose union bolt M10 30 3.0
Front brake master cylinder M6 10 1.0
Right rider footrest bracket and frame M8 28 2.8
Rear master cylinder and right rider footrest bracket M8 18 1.8
