–70–
Rear brake hose holder and brake torque rod M6 10 1.0
Rear wheel sensor and sensor housing
(FJR1300A)
M8 30 3.0
Rear wheel sensor lead bracket and swingarm
(FJR1300A)
M5 4 0.4
Rear brake hose (hydraulic unit to rear brake cali-
per) holder and swingarm (FJR1300A)
M6 7 0.7
Rear brake hose (rear brake master cylinder to hy-
draulic unit) holder and frame (FJR1300A)
M6 7 0.7
Rear brake hose (rear brake master cylinder to hy-
draulic unit) holder (FJR1300A)
M6 7 0.7
Rear wheel sensor lead holder (FJR1300A) M5 4 0.4
Brake hose union bolt (hydraulic unit) (FJR1300A) M10 30 3.0
Hydraulic unit and hydraulic unit bracket 1
(FJR1300A)
M8 16 1.6
Hydraulic unit bracket 1 and hydraulic unit bracket 2
(FJR1300A)
M8 16 1.6
Hydraulic unit bracket 2 and cross member
(FJR1300A)
M8 16 1.6
Clutch master cylinder M6 10 1.0
Clutch hose union bolt M10 30 3.0
Clutch release cylinder M6 10 1.0
Clutch release cylinder bleed screw M8 6 0.6
Front fender M6 6 0.6
Upper bracket pinch bolt M8 30 3.0
Lower bracket pinch bolt M8 23 2.3
Front fork cap bolt and inner tube M45 25 2.5
Front fork cap bolt and nut M10 25 2.5
Front fork damper rod assembly bolt M10 35 3.5
Handlebar and upper bracket M6 23 2.3
Grip end M6 4 0.4
Steering stem nut M28 115 11.5
Lower ring nut (steering stem) M30 18 1.8
Connecting arm and swingarm M10 48 4.8
Connecting arm and relay arm M10 48 4.8
Rear shock assembly and relay arm M10 40 4.0
Rear shock assembly and frame M12 64 6.4
Relay arm and frame M10 40 4.0
Swingarm pivot shaft and locknut M28 115 11.5
Swingarm pivot shaft and pivot shaft nut M18 125 12.5
Locknut retainer M6 10 1.0
Final drive housing oil filler bolt M14 23 2.3
Final drive housing oil drain bolt M14 23 2.3
Final drive assembly and swingarm M10 42 4.2
Part to be tightened Thread size
Tightening torque
Nm m • kg
