NOTE:
1. First, tighten the lower ring nut 52 Nm (5.2 m • kg, 37 ft • lb) using a torque wrench, then loosen the
lower ring nut completely.
2. Retighten the lower ring nut to specification.
Left rider footrest bracket and frame M8 28 2.8
Left rider footrest bracket and engine M10 49 4.9
Left rider footrest bracket, sidestand bracket, and
frame
M10 63 6.3
Ring gear bearing housing and final drive housing M10 40 4.0
Ring gear bearing housing and final drive housing M8 23 2.3
Stopper bolt M10 9 0.9
Gear coupling and final drive pinion gear M16 110 11.0
Final drive pinion gear bearing retainer M65 110 11.0
Sidestand and sidestand bracket M10 58 5.8
Centerstand bracket and frame M10 55 5.5
Centerstand and centerstand bracket M10 56 5.6
Rear frame and main frame (upper) M8 28 2.8
Rear frame and main frame (lower) M10 48 4.8
T-bar and frame M10 78 7.8
Fuel pump and fuel tank M5 4 0.4
Battery bracket and frame M6 10 1.0
Battery holder and battery bracket M6 10 1.0
Ignition coil M6 10 1.0
Part to be tightened Thread size
Tightening torque
Nm m • kg
