Yamaha FJR1300A(V) - 11. Front Cowling Left Inner Panel 1; 12. Front Cowling Right Inner Panel 1

–29–
G: Install the hexagon socket bolt
and the quick fastener.
11. FRONT COWLING LEFT
INNER PANEL 1
12. FRONT COWLING
RIGHT INNER PANEL 1
G: Monter la vis à tête hexagonale à
pans creux et le rivet démontable.
11. CACHE INTÉRIEUR
GAUCHE 1 DE
CARÉNAGE DE TÊTE
12. CACHE INTÉRIEUR
DROIT 1 DE CARÉNAGE
DE TÊTE
6 V 1 d = 5 (0.20), = 16 (0.63) (black)
7V1
G
G
6
7
1 1 d = 5 (0.20)
2C1
3 V 1 d = 5 (0.20), = 12 (0.47)
4 V 1 d = 5 (0.20), = 16 (0.63) (black)
5V2
2
5
4
1
3
*
1 V 1 d = 5 (0.20)
2C1
3 V 1 d = 5 (0.20), D = 13 (0.51)
4 V 1 d = 5 (0.20), = 20 (0.79)
5 V 1 d = 5 (0.20), = 16 (0.63) (black)
6V1
5
2
4
3
1
6
