6-16
DRIVE SHAF
T
AND FORW
ARD GEAR
REMOVING THE BALL BEARING
Remove:
Ball bearin
g
Adjusting shi
m(s)
A
For USA and Canada
B
Except for USA and Canada
CHECKING THE PINION
Check:
T
eeth
W
ear/damage
Replace.
CHECKING THE DRIVE SHAF
T
Check:
Drive sha
ft
W
ear/damage
Replace.
CHECKING THE FOR
W
ARD GEAR
Check:
T
eeth
W
ear/damage
Replace.
CHECKING THE BALL
BEARING
Check:
Ball bearin
g
Pitting/r
umbling
Replace.
NOTE:
Rotate the bearing and check if it tur
ns
smoothly
.
Slide hammer handle
1
:
YB-06096
Bearing pull
er
2
:
90890-06535
Stopper guide
plate
3
:
90890-06501
A
B
142
144
