POWER TIL
T (PT) UNIT
POWER TIL
T (PT) UNIT
DIS
ASSE
MBLI
NG/ASS
EMBLI
NG T
HE V
AL
V
ES AND P
UMP 1
Step
Job/Part
Q'ty
Remarks
1
Reserv
oir cap
1
2
O-ring
1
6.8 x 1
.9 mm
Not reusa
ble
3B
o
l
t
4
4P
T
m
o
t
o
r
1
5
O-ring
1
21.
7 x 3.5 mm
Not reusa
ble
6O
-
r
i
n
g
1
Not reusa
ble
7
Manual release rod
1
8P
i
n
1
9
O-ring
1
5.8 x 1
.9 mm
Not reusa
ble
10
Sponge
1
Not reusa
ble
11
Spring
2
Outside diameter 5.0 x Length 17
.0 mm
12
Manual release pin
2
13
Spring
2
Outside diameter 5.7 x Length 17
.2 mm
Continued on next page.
