5-22
POWER UNIT
REMOVING/INST
ALLING THE LEF
T SIDE ELECTRICAL COMPONENTS
2 (TWO
LIGHTING C
OILS MODEL)
Step
Job/Part
Q'ty
Remar
ks
1C
l
a
m
p
1
Not reusa
ble
2
Bolt (with washer)
2
Not reusa
ble
3
Charge coil
1
2 leads (Blue,
Brown)
4
Bolt (with washer)
4
Not reusa
ble
5
Lighting coil
1
2 le
ads (Green x 2)
6S
c
r
e
w
2
7
Coupler clamp
1
8
Bolt (with washer)
2
9
CDI unit
1
13 leads
For install
ation, rever
se the
remova
l
procedure.
