62
POWER TIL
T (PT) UNIT
DIS
ASSE
MBLI
NG/ASS
EMBLI
NG T
HE POWER T
IL
T
(PT)
CYLI
NDE
R
Step
Job/Part
Q'ty
Remarks
1
T
ilt ram assem
bly
1
2
Free piston
1
3
O-ring
1
20.8 x
2.4 mm
Not reusable
4
Backing ring
1
5
T
ilt cylinder
1
6
O-ring
1
26
.0 x 1.8
mm
Not reusable
7
Cylinder 1
8
O-ring
1
29
.7 x 1.9
mm
Not reusable
9
O-ring
1
20
.8 x 2.4
mm
Not reusable
10
Backup ring
1
11
T
ilt piston
1
12
Ball
1
13
Pin
1
Continued on next page.
