CRX-E320/NX-E700
15
■ DISPLAY DATA
Note : 1) F+, F- ..... Filament pin 2) DO ..... Serial data output 3) Test ..... Be left open if not used. 4) NP ..... No pin
Pin No.
Connection
1
F+
2
F+
3
NPNPNPNPNPNPNPNPNPNPNPNP
NPNPNPNPNPNPNPNPNPNPNPNP
NPNPNPNPNPNPNPNPNPNPNPNPNP
456789101112131415161718192021222324252627
Pin No.
Connection
28293031323334353637383940
Test
41
DO
42
DA
43
/CP
44
/CS
45
/RST
46
OSCO
47
V
DD
48
D-GND
49
L-GND
50
VDISP
51
NP
52
NP
53
F-
54
F-
● FIP1: HCA-17SM03T (FRONT/SMPS P.C.B.)
● PIN CONNECTION
● GRID ASSIGNMENT
1G
1
2G 3G 4G 5G 6G 7G 8G 9G 10G 11G 12G 13G 14G 15G 16G 17G 1G 1G
PATTERN AREA
n1
2345
678910
11 12 13 14 15
16 17 18 19 20
21 22 23 24 25
26 27 28 29 30
31 32 33 34 35
36 37 38 39 40
41 42 43 44 45
46 47 48 49 50
51 52 53 54 55
56 57 58 59 60
61 62 63 64 65
66 67
(2G~17G)
68 69 70
● ANODE CONNECTION
COM2 –COM3 COM15 COM16 COM17COM1
1G 2G –3G 15G 16G 17G
SEGB1
SEGB2
SEGB3
SEGB4
SEGB5
SEGB6
SEGB7
SEGB8
SEGB9
SEGB10
10 10 10 10 10 10
SEGB11
11
9
11 11 11 11 11
SEGB12
12 12 12 12 12 12
SEGB13
13 13 13 13 13 13
SEGB14
14 14 14 14 14 14
SEGB15
15 15 15 15 15 15
SEGB16
16 16 16 16 16 16
SEGB17
17 17 17 17 17 17
SEGB18
18
111111
222222
333333
4
5
6
7
8
9
4
5
6
7
8
9
4
5
6
7
8
9
4
5
6
7
8
9
4
5
6
7
8
9
4
5
6
7
8
18 18 18 18 18
SEGB19
19 19 19 19 19 19
SEGB20
20 20 20 20 20 20
SEGB21
21 21 21 21 21 21
SEGB22
22 22 22 22 22 22
SEGB23
23 23 23 23 23 23
SEGB24
24 24 24 24 24 24
SEGB25
25 25 25 25 25 25
SEGB26
26 26 26 26 26 26
SEGB27
27 27 27 27 27 27
SEGB28
28 28 28 28 28 28
SEGB29
29 29 29 29 29 29
SEGB30
30 30 30 30 30 30
SEGB31
31 31 31 31 31 31
SEGB32
32 32 32 32 32 32
SEGB33
33 33 33 33 33 33
SEGB34
34 34 34 34 34 34
SEGB35
35 35 35 35 35 35
COM1 COM2 –COM3 COM15 COM16 COM17
1G 2G –3G 15G 16G 17G
SEGA1 36 36 36 36 36 36
SEGA2 37 37 37 37 37 37
SEGA3 38 38 38 38 38 38
SEGA4 39 39 39 39 39 39
SEGA5 40 40 40 40 40 40
SEGA6 41 41 41 41 41 41
SEGA7 42 42 42 42 42 42
SEGA8 43 43 43 43 43 43
SEGA9 44 44 44 44 44 44
SEGA10
45 45 45 45 45 45
SEGA11
46 46 46 46 46 46
SEGA12
47 47 47 47 47 47
SEGA13
48 48 48 48 48 48
SEGA14
49 49 49 49 49 49
SEGA15
50 50 50 50 50 50
SEGA16
51 51 51 51 51 51
SEGA17
52 52 52 52 52 52
SEGA18
53 53 53 53 53 53
SEGA19
54 54 54 54 54 54
SEGA20
55 55 55 55 55 55
SEGA21
56 56 56 56 56 56
SEGA22
57 57 57 57 57 57
SEGA23
58 58 58 58 58 58
SEGA24
59 59 59 59 59 59
SEGA25
60 60 60 60 60 60
SEGA26
61 61 61 61 61 61
SEGA27
62 62 62 62 62 62
SEGA28
63 63 63 63 63 63
SEGA29
64 64 64 64 64 64
SEGA30
65 65 65 65 65 65
SEGA31
66 66 66 66 66 66
SEGA32
67 67 67 67 67 67
SEGA33
68 68 68 68 68 68
SEGA34
69 69 69 69 69 69
SEGA35
70 70 70 70 70 70
