CRX-E320/NX-E700
7
■ INTERNAL VIEW
215 (8-7/16")
308.4 (12-1/8")
15(9/16")
270.4 (10-5/8")
23 (15/16")
113 (4-7/16")
105 (4-1/8")
8
(5/16")
■ Player Section / プレーヤー部
Playback System / 再生システム
.................................................................................. CD, CD-R/RW
Audio Performance / オーディオ部性能 (1 kHz)
Signal-Noise ............................................................ 100 dB or more
Dynamic range .........................................................100 dB or more
Distortion and Noise ................................................ 0.005 % or less
DAC ........................................................................... 192 kHz/24-bit
■ Amplifier Section / アンプ部
Minimum RMS Output Power Per Channel / 定格出力
(6-ohm, 1 kHz, 0.5 % THD)
..................................................................................... 25 W + 25 W
Maximum RMS Output Power Per Channel / 実用最大出力
(6-ohm, 1 kHz, 10 % THD)
..................................................................................... 30 W + 30 W
Input Sensitivity/Impedance / 入力感度/インピーダンス
AUX etc. ............................................................. 300 mV/47 k-ohms
Frequency Response / 周波数特性 (1 W, 6-ohm)
CD etc. ..................................................... 20 Hz to 20 kHz ± 0.5 dB
Total Harmonic Distortion / 全高調波歪率 (6-ohm, 1 kHz, 1 W)
CD etc. .......................................................................0.08 % or less
Signal to Noise Ratio / S/N比 (IHF-A network)
CD etc. .......................................................................95 dB or more
Output level/Impedance / 出力レベル/インピーダンス
PHONES (Volume max.) ............................................. 1 V/32 ohms
■ Tuner Section / チューナー部
FM Section / FMチューナー部
Tuning Range / 受信周波数範囲
U, T, K, A, G, L models ................................ 87.50 to 108.00 MHz
J model ............................................................ 76.0 to 108.0 MHz
Sensitivity / 感度
S/N 30 dB ............................................................. 7 dBµVm (EMF)
AM Section / AMチューナー部
Tuning Range / 受信周波数範囲
U model ............................................................... 530 to 1700 kHz
T, K, A, G, L, J models........................................ 522 to 1629 kHz
Sensitivity / 感度
S/N 20 dB .................................................................. 60 dB (EMF)
■ General / 総合
Power Supply / 電源電圧
U model .................................................................. AC 120 V, 60 Hz
T, K, A, G, L, J models ......................... AC 100 to 240 V, 50/60 Hz
Power Consumption / 消費電力
................................................................................................. 55 W
Standby Power Consumption / 待機時消費電力
.................................................................................... 1.0 W or less
Dimensions (W x H x D) / 寸法（幅×高さ×奥行き）
....................... 215 x 113 x 308.4 mm (8-7/16" x 4-7/16" x 12-1/8")
Weight / 質量
......................................................................... 3.1 kg (6 lbs. 13 oz)
Finish / 仕上げ
Gold color...................................................................... T, A models
Black color ................................................................ G, L, J models
Silver color ........................................................... U, K, G, L models
Accessories / 付属品
Remote control x 1, Indoor FM antenna x 1, AM loop antenna x 1
* Specifications are subject to change without notice due to product
improvements.
※ 参考仕様および外観は予告なく変更されることがあります。
■ SPECIFICATIONS / 参考仕様
CRX-E320 NX-E700
Type / 型式 ................................. 2-way bass reflex speaker system/
Magnetic shielding type
2ウェイ・バスレス式／防磁型
Driver / スピーカーユニット
Woofer ..................................................... 11 cm (4-1/2") cone type
Tweeter ........................................................ 2.5 cm (1") dome type
Frequency Response / 再生周波数帯域
U, T, K, A, G and L models ..................... 60 Hz to 28 kHz (-10dB)
J model .................................................... 60 Hz to 80 kHz (-30dB)
Impedance / インピーダンス ................................................. 6 ohms
Nominal Input / 許容入力 .......................................................... 40 W
Maximum Input / 最大入力 ..................................................... 110 W
Sensitivity / 出力音圧レベル ..................................... 85 dB/2.83 V/m
Crossover Frequency / クロスオーバー周波数 ....................... 3 kHz
Input Terminal / 入力端子 .................................. Screw/Banana type
Dimensions (W x H x D) / 寸法（幅×高さ×奥行き）
......................................................... 165 mm x 255 mm x 183 mm
(6-1/2" x 10-1/16" x 7-3/16")
Weight / 質量 .........................................................3.4 kg (7 lbs 8 oz)
Finish / 仕上げ .................................................................. Black color
Accessories / 付属品 .................................. Speaker cable (4 m) x 2
* Specifications are subject to change without notice due to product
improvements.
※ 参考仕様および外観は予告なく変更されることがあります。
• DIMENSIONS/寸法図
Unit: mm (inch)
単位：mm（インチ）
165(6-1/2") 183(7-3/16")
255(10-1/16")
MAIN (1) P.C.B.
TUNER MODULE
FRONT / SMPS (3) P.C.B.
CONNECTOR P.C.B.
MAIN (2) P.C.B.
FRONT / SMPS (2) P.C.B
CD MECHANISM UNIT
FRONT / SMPS (1) P.C.B
78
1 2 3 4 1
2
3
4
5
6
7
8
5
6
U .......... U.S.A. and Canadian models
T .......... Chinese model
K .......... Korean model
A .......... Australian model
G .......... European model
L ........... Singapore model
J ........... Japanese model
CRX-E320 NX-E700
