CRX-E320/NX-E700
6
22
Safety Measures
• Some internal parts in this product contain high voltages and are dangerous. Be sure to take safety measures during
servicing, such as wearing insulating gloves.
• C901 on the FRONT/SMPS (3) P.C.B. are dangerous, for a high voltage is retained there even after the power is turned
off.
Before the repair work, connect a resistor about 5 k-ohms/10 W between terminals of the capacitor to force discharge.
After the repair work, also perform force discharge by connecting a resistor about 5 k-ohms/10 W between terminals of
the capacitor.
安全対策
AC IN
(Top view)
FRONT/SMPS (3) P.C.B.
CONNECTOR P.C.B. (Top view)
MAIN (1)
(BN93)
MAIN (1)
(CN92)
5 k-ohms
10W
