MOTIF XS6/MOTIF XS7/MOTIF XS8
22
• Display assembly
<Bottom view>
JKAN-LC
[D80]
[D50]
[D60]
[D60]
[D60]
Claw
CN202
CN203
(ツメ)
Display angle
(ディスプレイアングル)
Display angle
(ディスプレイアングル)
(ディスプレイAssy)
LCD
(液晶ディスプレイ)
(※ディスプレイアングルを
  外した状態)
FFC Cable
(FFCケーブル)
(ツメの部分を矢印の方向に解除し
て、コネクタを外します。)
Remove the connector by releasing
the claws in the direction of the arrow.
JKAN-LC
* After the display angle is
removed
<Bottom view>
PNA
PNC
PNB-PN
[90B]
[40E] [40E]
[40F]
[C]
[90B]
(位置決めピンC)
(位置決めピンA)
(位置決めピンB)(位置決めピンB)
[40F]
Positioning pin A
Positioning pin B Positioning pin B Positioning pin C
* This gure shows the MOTIF XS6.(この図は MOTIFXS6 です。
9. PNA Circuit Board
(Time required: About 6 minutes)
9-1 Remove the four (4) knobs and five (5) slider
knobs in the portion marked [A]. (Fig. 7)
* The slider knobs can be attached in the
opposite direction. When attaching the slider
knobs, attach them in the direction as they
were before removal.
9-2 Remove the side panel R and side panel L.
(See procedure 1.)
9-3 Remove the control panel assembly.
(See procedure 2.)
9-4
Remove the two (2) each screws marked [70]. The
two (2) PCB angle 1 (A) can then be removed. (Fig. 7)
9-5 Remove the three (3) screws marked [410]. The
shield plate JA can then be removed. (Fig. 7)
9-6 Remove the three (3) screws marked [40E]. The
PNA circuit board can then be removed. (Fig. 9)
* When installing the PNA circuit board, fit the
holes to the positioning pins A fi rst, and then
tighten the screws. (Fig. 9)
* The PNA circuit board contains the following
buttons. (Photo 3)
• [20]: Push button, MR (Gray) 2 pcs.
• [30]: Push button, M (Gray) 2 pcs.
9. PNA シート(所要時間:約 6 分)
9-1 A 部のノブ 4 個とスライダーノブ 5 個を外します。
(図 7)
※ スライダーノブは向きを逆さにしても取り付けら
れます。スライダーノブを取り付けるときは、元
の向きに取り付けてください。
9-2 サイドパネル R とサイドパネル L を外します。
(1 項参照)
9-3 コンパネ Assy を外します。(2 項参照)
9-4 [70] 2 て、PCB
1(A) 2 個外します。(図 7)
9-5 [410] ネジ 3 本を外して、シールド板 JA を外し
ます。(図 7)
9-6 [40E] ネジ 3 本を外して、PNA シートを外し
す。(図 9)
※ PNA シートを取り付けるときは、位置決めピン A
に差し込んでからネジ止めしてください。(図 9)
※ PNA シートには下記のボタンがついています。
(写真 3)
・[20]:プッシュボタン (MR)( ) 2
・[30]:プッシュボタン (M)( ) 2
Fig.8( 8)
Fig.9( 9)
[D50]: BindHeadTappingScrew-B(B タイト+ BIND)3.0X10MFZN2W3(WE774200)
[D60]: BindHeadTappingScrew-B(B タイト+ BIND)3.0X8MFZN2W3(WE774300)
[D80]: BindHeadTappingScrew-B(B タイト+ BIND)3.0X8MFZN2W3(WE774300)
[40E],[40F]:BindHeadTappingScrew-B(B タイト+ BIND)3.0X6MFZN2W3(WE936300)
[90B]: BindHeadTappingScrew-B(B タイト+ BIND)3.0X6MFZN2W3(WE936300)
