CHARGING SYSTEM
8-15
EAS30497
TROUBLESHOOTING
The battery is not being charged.
TIP
• Before troubleshooting, remove the following part(s):
1. Rider seat
1. Check the fuse.
(Main)
Refer to “CHECKING THE FUSES”
on page 8-194.
NG
Replace the fuse.
OK
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-195.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
3. Check the stator coil.
Refer to “CHECKING THE STA-
TOR COIL” on page 8-202.
NG
Replace the stator coil assembly.
OK
4. Check the rectifier/regulator.
Refer to “CHECKING THE RECTI-
FIER/REGULATOR” on page
8-202.
NG
Replace the rectifier/regulator.
OK
5. Check the entire charging system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-13.
NG
Properly connect or repair the charging
system’s wiring.
OK
The charging system circuit is OK.

Yamaha MT 10 2016 Specifications

General

Displacement	998 cc
Bore x Stroke	79.0 mm x 50.9 mm
Maximum Power	118.0 kW (160.4PS) @ 11, 500 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Transmission	Chain
Front Tire	120/70 ZR17M/C (58W)
Rear Tire	190/55 ZR17M/C (75W)
Length	2, 095 mm
Width	800 mm
Height	1, 110 mm
Seat Height	825 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	135 mm
Wet Weight	210 kg
Fuel Tank Capacity	17 liters
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Compression Ratio	12.0:1
Torque	111 Nm @ 9, 000 rpm
Front Suspension	Telescopic forks, Ø 43 mm
Rear Suspension	Link-type suspension
Front Brake	Dual 320mm hydraulic disc, ABS
Rear Brake	Hydraulic disc, 220 mm
Frame	Aluminum Deltabox
