EAU87110
Multi-function meter unit
The multi-function meter unit is also
equipped with a backlight setting
mode.
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
operator and increase the risk of an
accident.
EAU86831
Speedometer
The speedometer shows the vehicle’s
traveling speed.
EAU87170
Tachometer
The tachometer allows the rider to
monitor the engine speed and keep it
within the ideal power range.
NOTICE
ECA10032
Do not operate the engine in the ta-
chometer red zone.
Red zone: 11000 r/min and above
1. Transmission gear display
2. VVA (variable valve actuation) indicator
3. “RESET” button
4. Multi-function display
5. Fuel meter
6. “SELECT” button
7. Speedometer
8. Tachometer
1
2
3
4
5
6
7
8
