Instrument and control functions
4-15
4
To release the helmet from the hel-
met holder
Remove the rider seat, remove the hel-
met from the helmet holder, and then
install the seat.
EAU37491
Sidestand
The sidestand is located on the left
side of the frame. Raise the sidestand
or lower it with your foot while holding
the vehicle upright.
EWA14191
The vehicle must not be ridden with
the sidestand down, or if the side-
stand cannot be properly moved up
(or does not stay up), otherwise the
sidestand could contact the ground
and distract the operator, resulting
in a possible loss of control.
EAU15397
Starting circuit cut-off system
This system prevents in-gear engine
starts unless the clutch lever is pulled.
Periodically check the system via the
following procedure.
z This check is most reliable if per-
formed with a warmed-up engine.
z See pages 4-1 and 4-9 for switch
operation information.
