Yamaha PG-1 - Shift pedal; Brake lever; Brake pedal

Instrument and control functions
4-5
4
EAU37462
Shift pedal
The shift pedal is located on the left
side of the motorcycle. This motorcy-
cle is equipped with a constant-mesh 4
speed transmission.
TIP
Use your toes to shift up and your heel
to shift down.
EAU12892
Brake lever
The brake lever is located on the right
side of the handlebar. To apply the
front brake, pull the lever toward the
throttle grip.
EAU39542
Brake pedal
The brake pedal is located on the right
side of the vehicle.
This model is equipped with a unified
brake system.
When pressing down on the brake
pedal, the rear brake and a portion of
the front brake are applied. For full
braking performance, apply both the
brake lever and the brake pedal simul-
taneously.
1. Shift pedal
1
1. Brake lever
1
1. Brake pedal
1
