Instrument and control functions
4-8
4
EAUT3171
Seat
To open the seat
1. Place the vehicle on the center-
stand.
2. Insert the key in the lock, and then
turn it clockwise.
3. Fold the seat up.
To close the seat
1. Fold the seat down, and then push
it down to lock it in place.
2. Remove the key.
Make sure that the seat is properly se-
cured before riding.
EAUV0850
Helmet holders
The helmet holders are located under
the seat.
To secure a helmet to a helmet hold-
er
1. Open the seat. (See page 4-8.)
2. Attach the D-ring of the helmet
strap to a helmet holder, and then
securely close the seat.
WARNING! Never ride with a
helmet attached to the helmet
holder, since the helmet may hit
objects, causing loss of control
and possibly an accident.
[EWA10162]
1. Seat lock
2. Seat
1. Helmet holder
2. D-ring
