• Type GaAlAs
• Wave length 780 nm
• Emission duration continuous
Warning for power supply
The primary side of the power supply carries live mains voltage when the player is connected to the mains even when
the player is switched off !
This primary area is not shielded so it is possible to touch copper tracks and/or components when servicing the player.
Service personnel have to take precautions to prevent touching this area or components in this area.
Note:
The screws on the DVD mechanism may never be touched, removed or re-adjusted.
Handle the DVD mechanism with care when the unit has to be exchanged!
The DVD mechanism is very sensitive for dropping or giving shocks.
Laser Diode Properties
• Laser output max. 44.6 µW *
* This output is the value mea-
sured at a distance of about
200 mm (7.9 in) from the ob-
jective lens surface on the
optical pick-up block.
