6-34
PERIODIC MAINTENANCE AND MINOR REPAIR
6
To service the rear wheel
Raise the rear wheel off the ground
by using a machine stand or, if a
machine stand is not available, by
placing a jack either under each side
of the frame in front of the rear wheel
or under each side of the swingarm.
2. Loosen the wheel axle holder
nuts, then the wheel axle.
3. Lift the front wheel off the ground
according to the procedure on
page 6-33.
4. Pull the wheel axle out, and then
remove the wheel.
ECA00048
cC
Do not apply the brake after the
wheel has been removed together
with the brake disc, otherwise the
brake pads will be forced shut.
EAU03605
Front wheel
To remove the front wheel
EW000122
w
8 It is advisable to have a
Yamaha dealer service the
wheel.
8 Securely support the machine
so that there is no danger of it
falling over.
1. Remove the tripmeter cable from
the front wheel.
