6. With the arrow mark pointing in the direc-
tion shown, insert the dipstick completely
into the oil filler hole and then remove it
again to check the oil level.
The engine oil should be between the mini-
mum and maximum level marks.
7. If the engine oil is at or below the mini-
mum level mark, add sufficient oil of the
recommended type to raise it to the cor-
rect level.
8. Install the dipstick with the arrow pointing
in the direction shown.
1. Engine oil dipstick
2. Arrow mark
1. Engine oil dipstick
2. Maximum level mark
3. Minimum level mark
