Yamaha WOLVERINE 2015 - Differential Gear Oil

8-22
8
6. Refill with the recommended final gear oil
up to the brim of the filler hole. NOTICE:
Be sure no foreign material enters the
final gear case.
[ECB00422]
7. Check the oil filler bolt gasket for dam-
age, and replace it if necessary.
8. Install the oil filler bolt and its gasket, and
then tighten the bolt to the specified
torque.
9. Check for oil leakage. If oil leakage is
found, check for the cause.
10. Install the panel by installing the bolts,
and then tightening them to the specified
torque.
EBU36082
Differential gear oil
Checking the differential gear oil level
1. Park the vehicle on a level surface.
2. Remove the differential gear oil filler bolt
and its gasket, and then check the oil lev-
el. It should be up to the brim of the filler
hole.
Recommended oil:
SAE 80 API GL-4 Hypoid gear oil
Oil quantity:
0.64 L (0.68 US qt, 0.56 Imp.qt)
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kgf, 17 ft·lbf)
Tightening torques:
Rear bottom panel bolt:
9 Nm (0.9 m·kgf, 6.5 ft·lbf)
